Facility

LCM custom-builds each Press with regard to the Press Application & the Technical Requirements of our Customers

Inventory

Majority of LCM’s Material Inventory is sourced from Taiwan, Germany and Japan.
LCM Hydraulic Presses are equipped with variable displacement Bosch Rexroth Pumps and Teco Westinghouse High Efficiency Motors.
High Quality, Seamless Tube or Forgings are used in conjunction with high quality Pistons for the manufacture of Hydraulic Cylinders.

Cutting

NC Flame Cutting Machine with Table Area 12,000 x 3,400 mm.

Welding

Metal Inert Gas Welding (MIG) is used throughout the fabrication of the Press Structure. Tungsten Inert Gas Welding (TIG) is used for the manufacture of high pressure Hydraulic Piping.

Annealing

160 Metric ton Gas Annealing Furnace with 12,000 x 5,000 x 4,500 mm Table Area and a maximum Operational Temperature of 950 degrees Celsius.

Precision CNC Boring Mills with 200 mm Spindle Diameter

X-axis Travel = 24,000 mm
Y-axis Travel = 4,700 mm
Z-axis Travel = 1,600 mm
W-axis Travel = 1,600 mm

Precision CNC Boring Mills with 200 mm Spindle Diameter

X-axis Travel = 20,000 mm
Y-axis Travel = 6,000 mm
Z-axis Travel = 1,900 mm
W-axis Travel = 1,400 mm

5 Face Vertical Milling Machine

5 Face Vertical Milling Machine
X-axis Travel = 82,000 mm
Y-axis Travel = 4,000 mm
Z-axis Travel = 1,000 mm
W-axis Travel = 1,300 mm
